Desktop PNP VP-2800D WNE belt machine up to 90 x 8mm feeders below 8000USD

Our latest design for VP-2800D belt machine including 3 sides feeder and high performance winder motors.

3 side feeder machine has reduced working area 260 x 500mm!

You see custom build 8mm deep 16mm feeder lines to supply tall parts standard is 6.5mm deep.

Machine working video

F1E5EEA0025947722C8BA996312B7DFB.mp4

MP4 Video/Audio File 13.6 MB

Download
